Be1 25 sync check relays are solid state synchronism check relays designed to permit breaker closure when the desired maximum phase angle conditions have held for a specified minimum time.

Sync check relay 25.

Sync check 25 modern sync check compensates for pt connections and phase angle. The maximum allowable phase angle and time delay requirements can be set on front panel thumbwheel switches. Be1 25 sync check relays are recommended for situations that require verification of synchronism prior to closing a circuit breaker. The synchro check relay can be used to assist in the semi automatic parallelling of two ac power systems.

The sync check relay is ansi element 25. Reestablishing a connection between two parts of a power system. Paralleling a generator to a system. We would like to show you a description here but the site won t allow us.

Sync check relay supervision automatic synchronizer matches v and f and closes. Thank you for your attention. For this reason it is normal practice to have the sync check relay function provided in a different package than the automatic synchronizing relay to. Out of sync closing can create significant impact on the power system and in worst case can damage the equipment due to high short circuit currents.

Connecting two electrical systems that are not closely matched can cause expensive damage and disturbance to the electrical. 25s 25v synchronism check relays solid state relays designed for distribution systems to verify that the voltages on either side of a circuit breaker are synchronized and in the proper phase and magnitude relationship to allow automatic closing. The volt free relay contacts change state when the voltage level phase relationship and frequency are within the selected synchronising limits. The be1 25 sync check relay is designed to measure the phase angle between the monitored single phase voltages on the line and bus sides of a breaker and verify this angle is less than or equal to the front panel setting.

If the measured angle has met this criteria for.
